How rtd sensor works ?

RTD (Resistance Temperature Detector) sensors work based on the principle that the electrical resistance of certain materials changes with temperature. RTDs are typically made of pure metals, such as platinum, due to their high temperature coefficient of resistance (TCR), which means their resistance changes significantly with temperature.

The basic working principle of an RTD sensor can be summarized in the following steps:

  1. The RTD element: An RTD sensor consists of a thin wire made of a pure metal, usually platinum, which is wound around a ceramic or glass core. The RTD element is designed to exhibit a specific resistance at a reference temperature, typically 0°C or 100°C.
  2. Applying a current: A known electrical current is passed through the RTD element, typically using a Wheatstone bridge circuit. The electrical resistance of the RTD element causes a voltage drop across it, which can be measured.
  3. Measuring resistance: The resistance of the RTD element is measured using a bridge circuit, which compares the RTD resistance with known reference resistances. The bridge circuit is typically balanced, meaning the voltages across its arms are equal, when the RTD element is at the reference temperature.
  4. Temperature-dependent resistance: As the temperature changes, the electrical resistance of the RTD element changes proportionally. This change in resistance causes an imbalance in the Wheatstone bridge circuit, resulting in a measurable voltage difference.
  5. Temperature calculation: The voltage difference obtained from the Wheatstone bridge circuit is used to calculate the temperature using a calibration curve or a mathematical formula that relates the resistance of the RTD element to temperature. The calibration curve is typically determined during the manufacturing process and is specific to the RTD element being used.
  6. Output signal: The calculated temperature is then typically converted into a standardized output signal, such as a 4-20 mA current loop, a voltage signal, or a digital signal, depending on the application and the requirements of the system where the RTD sensor is being used.

It’s important to note that RTD sensors are known for their high accuracy and stability, typically offering temperature measurement with precision of up to 0.1°C or better, making them suitable for a wide range of applications where precise temperature control or monitoring is critical.
